Computer in (D-sub 15pin) x 2(Share with component)
Monitor out (D-sub 15pin) x 1
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
HDMI x 1
Audio in (Mini Jack) x 2
Audio out (Mini Jack) x 1
Audio L/R in (RCA) x 1
Speaker x 1 (10W)
USB (Type Mini B) x1 (Download & page/down)
RS232 (DB-9pin) x 1
LAN (RJ45) x 1
體積 (寬x高x縱深, mm)
287.3 x 114.4 x 232.6 公釐
HDTV支援
480i, 480p, 576i, 576p, 720p, 1080i, 1080p
影像支援
NTSC, PAL, SECAM
3D 支援與相容
Frame Sequential: 最高達480i
Frame Packing: 最高達24 Hz 1080p
Side by Side: 最高達60Hz 1080i
Top Bottom: 最高達24Hz 1080p
重量(公斤)
2.6 公斤
噪音值(一般/經濟)
32/28 dBA (一般/經濟模式)
支援電源供應
AC100 to 240 V, 50 to 60 Hz
電源消耗功率
270W(一般)，待機<0.5W
語言播放
支援28種語言
畫質模式種類
動態模式/簡報模式/sRGB相片模式/劇院模式/(3D)/自訂模式1/自訂模式2
標準配備
Lens Cover
Remote Control w/ Battery
Power Cord (by region)
User Manual CD
Quick Start Guide
Warranty Card (by region)
VGA(D-sub 15pin) Cable
*Lamp life results will vary depending on environmental
conditions and usage. Actual product's features and
specifications are subject to change without notice.
